뉴타닉스 가상 컴퓨팅 플랫폼(Nutanix Virtual Computing Platform)은 가상화 환경에서 동작하는 가상머신의 성능을 최적화하기 위하여 서버, 스토리지, 네트워크를 하나의 노드에 컨버지드한 플랫폼으로, 뉴타닉스 분산 파일 시스템(Nutanix Distributed File System)을 통하여 엔터프라이즈 레벨의 성능(Performance), 효율성(Efficiency), 안정성(Reliability), 확장성(Scalability)을 제공할 뿐만 아니라 아주 쉽고 간단한 설정 및 관리기능을 제공한다.

하이퍼컨버지드 인프라 완벽 가이드

Nutanix 제품의 상세한 모델별 사양은 Nutanix Hardware Platforms에서 확인하시기 바랍니다.

NX-1000 Series

  • NX-1065S-G5
    Per Node 4 per Appliance
    Server Compute Single Intel Broadwell
    E5-2609v4 [8 cores / 1.7 GHz]
    E5-2620v4 [8 cores / 2.1 GHz]
    E5-2650v4 [12 cores / 2.2 GHz]
    Storage Capacity (Hybrid) 1x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    2x HDD: [2 TB, 4 TB, 6 TB or 8 TB]
    Storage Capacity (All Flash) 3x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB or 3.84 TB]
    Memory 64 GB, 96 GB, 128 GB or 256 GB
    Network Configurations 2x 1GbE RJ45, and 1x 100 Mbps RJ45 (IPMI)
    GPU N/A
  • NX-1065-G5
    Per Node 4 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2620v4 [16 cores / 2.1 GHz]
    E5-2640v4 [20 cores / 2.4 GHz]
    Storage Capacity (Hybrid) 1x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    2x HDD: [2 TB, 4 TB, 6 TB or 8 TB]
    Storage Capacity (All Flash) 3x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB or 3.84 TB]
    Memory 64 GB, 96 GB, 128 GB, 192 GB, 256 GB, 384 GB, 512 GB or 1 TB
    Network Configurations 2x 1 GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on: Dual-Port 1 GbE or Dual-Port 10 GbE or Quad-Port 10 GbE or Dual-Port 10 GBASE-T
    GPU N/A
  • NX-1155-G5
    Per Node 1 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2620v4 [16 cores / 2.1 GHz]
    Storage Capacity (Hybrid) 2x SSD: [1.2 TB]
    HDD: 4x [4 TB], 6x [4 TB], 8x [4 TB], 10x [4 TB], 8x [6TB], 10x [6TB]
    Storage Capacity (All Flash) 12x SSD: [1.2 TB, 1.92 TB]
    Memory 64GB RAM
    Network Configurations 4x 1GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on NIC (Optional): Dual-Port 10 GbE SFP+, Dual-Port 10 GbE BASE-T, or Quad-Port 10 GbE SFP+
    GPU N/A
Download Datasheet

NX-3000 Series

  • NX-3060-G5
    Per Node 4 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2620v4 [16 cores / 2.1 GHz]
    E5-2640v4 [20 cores / 2.4 GHz]
    E5-2650v4 [24 cores / 2.2 GHz]
    E5-2680v4 [28 cores / 2.4 GHz]
    E5-2695v4 [36 cores / 2.1 GHz]
    Storage Capacity (Hybrid) 2x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    4x HDD: [1 TB or 2 TB]
    Storage Capacity (All Flash) 6x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB or 3.84 TB]
    Memory 128 GB, 192 GB, 256 GB, 384 GB, 512 GB or 1 TB
    Network Configurations 2x 1 GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on: Dual-Port 10 GbE or Quad-Port 10 GbE or Dual-Port 10 GBASE-T
    GPU N/A
  • NX-3155G-G5
    Per Node 1 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2650v4 [24 cores / 2.2Ghz]
    E5-2667v4 [16 cores / 3.2Ghz]
    E5-2680v4 [28 cores / 2.4 GHz]
    E5-2695v4 [36 cores / 2.1GHz]
    Storage Capacity (Hybrid) 2x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB]
    4x HDD: [2 TB, 4 TB, 6 TB or 8 TB]
    Storage Capacity (All Flash) 6x SSD: [480 GB, 800 GB,960 GB, 1.2 TB, 1.6 TB, 1.92 TB, or 3.84 TB]
    Memory 128 GB, 192 GB, 256 GB, 384 GB, 512 GB, 640 GB, 768 GB, 1 TB, 1.5 TB
    Network Configurations 4x 1 GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on NIC: 1x/2x/3x Dual-Port 10 GBASE-T, 1x/2x/3x Dual-Port 10G SFP+, 1x/2x/3x Quad-Port 10GbE
    GPU 2x M10 or 2x M60
  • NX-3175-G5
    Per Node 1 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2650v4 [24 cores / 2.2 GHz]
    E5-2667v4 [16 cores / 3.2 GHz]
    E5-2680v4 [28 cores / 2.4 GHz]
    E5-2695v4 [36 cores / 2.1 GHz]
    E5-2699v4 [44 cores / 2.2 GHz]
    Storage Capacity (Hybrid) 2x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    2x HDD: [2 TB, 4 TB, 6 TB or 8 TB]
    Storage Capacity (All Flash) 4x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB or 3.84 TB]
    Memory 128 GB, 192 GB, 256 GB, 384 GB, 512 GB, 640 GB, 768 GB, 1 TB or 1.5 TB
    Network Configurations 2x 10 GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on: Dual-Port 10 GbE, Quad-Port 10 GbE or Dual-port 10GBASE-T
    GPU 1x PCIe expansion slot; 1x M10 or 1x M60
Download Datasheet

NX-6000 Series

  • NX-6035C-G5
    Per Node 2 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2609v4 [16 cores / 1.7 GHz]
    E5-2620v4 [16 cores / 2.1 GHz]
    Storage Capacity (Hybrid) 1x SSD: [800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    5x HDD: [4 TB, 6 TB or 8 TB]
    Storage Capacity (All Flash) 6x SSD: [800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB or 3.84 TB]
    Memory 64 GB, 128 GB, 192 GB, 256 GB
    Network Configurations 2x 1 GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on: Up to 2x Dual-Port 10 GbE or 2x Quad-Port 10 GbE or 2x Dual-Port 10 GBASE-T
    GPU N/A
  • NX-6035-G5
    Per Node 2 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2620v4 [16 cores / 2.1 GHz]
    E5-2640v4 [20 cores / 2.4 GHz]
    Storage Capacity (Hybrid) 1x SSD: [800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    5x HDD: [4 TB, 6 TB or 8 TB]
    Storage Capacity (All Flash) N/A
    Memory 64 GB, 128 GB, 192 GB, 256 GB, 384 GB, 512 GB or 1 TB
    Network Configurations 2x 1 GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on: Up to 2x Dual-Port 10 GbE or 2x Quad-Port 10 GbE or 2x Dual-Port 10 GBASE-T
    GPU N/A
  • NX-6155-G5
    Per Node 1 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2620v4 [16 cores / 2.1 GHz]
    E5-2640v4 [20 cores / 2.4 GHz]
    E5-2650v4 [24 cores / 2.2 GHz]
    E5-2680v4 [28 cores / 2.4 GHz]
    E5-2695v4 [36 cores / 2.1 GHz]
    Storage Capacity (Hybrid) 2x SSD: [800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    10x HDD: [4 TB or 6 TB]
    Storage Capacity (All Flash) 12x SSD: [800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB or 3.84 TB]
    Memory 64 GB, 128 GB, 192 GB, 256 GB, 384 GB, 512 GB, 640 GB, 768 GB, 1 TB or 1.5 TB
    Network Configurations 4x 1 GbE, 1x 1 GbE RJ45 (IPMI)
    Add-on: Up to 2x Dual-Port 10 GbE SFP+ or 2x Quad-Port 10 GbE SFP+ or 2x Dual-Port 10 GBASE-T
    GPU N/A
Download Datasheet

NX-8000 Series

  • NX-8150-G5
    Per Node 1 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2667v4 [16 cores / 3.2 GHz]
    E5-2680v4 [28 cores / 2.4 GHz]
    E5-2695v4 [36 cores / 2.1 GHz]
    E5-2699v4 [44 cores / 2.2 GHz]
    Storage Capacity (Hybrid) 4x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    20x HDD: [1 TB or 2 TB]
    Storage Capacity (All Flash) 24x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    Memory 128 GB, 192 GB, 256 GB, 384 GB, 512 GB, 640 GB, 768 GB, 1 TB or 1.5 TB
    Network Configurations 2x 10GBASE-T, 1x 1GbE RJ45 (IPMI)
    Add-on: Up to 2x Dual-port 10GbE SFP+ or 2x Quad-port 10GbE SFP+ or 2x Dual-port 10GBASE-T or 2x Dual-port 40GbE QSFP+
    GPU N/A
  • NX-8035-G5
    Per Node 2 per Appliance
    Server Compute Dual Intel Broadwell
    E5-2640v4 [20 cores / 2.4 GHz]
    E5-2643v4 [12 cores / 3.4 GHz]
    E5-2650v4 [24 cores / 2.2 GHz]
    E5-2680v4 [28 cores / 2.4 GHz]
    E5-2695v4 [36 cores / 2.1 GHz]
    Storage Capacity (Hybrid) 2x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB or 1.92 TB]
    4x HDD: [4 TB, 6 TB or 8 TB]
    Storage Capacity (All Flash) 6x SSD: [480 GB, 800 GB, 960 GB, 1.2 TB, 1.6 TB, 1.92 TB or 3.84 TB]
    Memory 128 GB, 192 GB, 256 GB, 384 GB, 512 GB or 1 TB
    Network Configurations 2x 1 GbE, 1x 1GbE RJ45 (IPMI)
    Add-on: Up to 2x Dual-port 10GbE or 2x Quad-port 10GbE or 2x Dual-port 10GBASE-T
    GPU N/A
Download Datasheet
